MS-QD4
- Energy
- 3.63kWh
- Voltage
- 25.6V
- Capacity
- 142Ah
- Starting Current
- 1,500A instant / 1,000CCA
- Weight
- 25.6kg
Specialty Battery Systems
MS-QD4 / MS-QD5 / MS-QD7
Emergency Starting Power Supply for Trucks
LiFePO4 emergency starting power family for trucks with forced-start capability and high instantaneous starting current.
- Battery Energy
- 3.63-8.03kWh
- Nominal Voltage
- 25.6V
- Starting Current
- Up to 3,500A
- Cycle Life
- 4,000 cycles
Models & Configurations
One Series. Confirmed Options.
All models and configurations remain on this series page. Select final specifications according to the project requirement.
MS-QD5
- Energy
- 7.10kWh
- Voltage
- 25.6V
- Capacity
- 280Ah
- Starting Current
- 3,500A instant / 2,500CCA
- Weight
- 56kg
MS-QD7
- Energy
- 8.03kWh
- Voltage
- 25.6V
- Capacity
- 314Ah
- Starting Current
- 3,500A instant / 2,200CCA
- Weight
- 58kg
Key Benefits
Designed Around Real Energy Needs.
01
Forced-start function
02
High instantaneous starting current
03
Wide operating temperature
04
Parallel terminal support
05
Stainless-steel module design
Applications
Truck Emergency StartingFleet SupportCold-Weather Starting
Technical Specifications
Confirmed Product Data.
- Battery Material
- Lithium iron phosphate
- Charging Voltage
- 29.2V
- Forced Start Cut-Off
- 22.4VDC
- Operating Temperature
- -30-55°C
- Communication
- Customizable Bluetooth
