MS-Q01
- Voltage
- 12.8V
- Capacity
- 100Ah
- Series Mode
- 4S1P
- Continuous Current
- 100A
- Cycle Life
- 6,000 cycles
Specialty Battery Systems
MS-Q01 / MS-Q05 / MS-Q07
Lithium Battery Replacement for Lead-Acid Battery
IP67 LiFePO4 battery family designed as a long-life replacement for lead-acid battery applications.
- Nominal Voltage
- 12.8 / 25.6V
- Capacity
- 100-314Ah
- Protection Class
- IP67
- Cycle Life
- 6,000-8,000 cycles
Models & Configurations
One Series. Confirmed Options.
All models and configurations remain on this series page. Select final specifications according to the project requirement.
MS-Q05
- Voltage
- 25.6V
- Capacity
- 200Ah
- Series Mode
- 8S1P
- Continuous Current
- 200A
- Cycle Life
- 6,000 cycles
MS-Q07
- Voltage
- 25.6V
- Capacity
- 314Ah
- Series Mode
- 8S1P
- Continuous Current
- 150A
- Cycle Life
- 8,000 cycles
Key Benefits
Designed Around Real Energy Needs.
01
Lead-acid replacement format
02
IP67 protection
03
Built-in intelligent BMS
04
Multiple mounting options
05
Optional Bluetooth monitoring
Applications
Lead-Acid ReplacementResidential SystemsCommercial Systems
Technical Specifications
Confirmed Product Data.
- Battery Material
- Lithium iron phosphate
- Communication
- Customizable Bluetooth module
- Charging Temperature
- 0-50°C
- Discharge Temperature
- -20-55°C
- Output
- Terminal block
